SCD 119-040-120 ACP3N IC908
| Drill Bit Size / Cutting Diameter (DC) | 11.9 mm | Cutting Edge Material | Carbide |
| Decimal Equivalent | 0.4685″ | Tool Type | Solid Carbide Drills |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 11.9 mm | Grade | IC908 |
| Length Group | 3xD | Measurement Type | Metric |
| Coating | TiAlN | Series/List # | 2464 |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Usable Length (LU) | 40 mm |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Length Chip Flute (LCF) | 55 mm |
| Coolant Supply Property (CSP) | Coolant Thru | Overall Length (OAL) | 102 mm |
| Point Angle (SIG) | 118 Degrees | Flute Count (NOF) | 2 |
| Flute Helix Angle (FHA) | 30 Degrees | Cutting Direction (HAND) | Right Hand |
| Shank Length (LS) | 45 mm | Body Material | Carbide |
| Shape | Solid Carbide |
Product Features
| Family Description | DIN 6537 solid carbide drills with coolant holes, drilling depth 3xD. | Country of Origin | Israel |
Shipping Info
Package Weight
0.280
