MEW 1500S1258154T 1.5000
Indexable End Mill; 1-1/2″ Dia. × 1-1/4″ Shank Dia. × 8″ OAL × 0.5906″ LU ; 4 FL ; Round Shank ; Series M-FOUR
| Cutting Diameter (DC/DCX) | 1-1/2″ | Tool Type | End Mill |
| Cutting Diameter (DC) | 1-1/2″ | Usable Length (LU) | 0.5906″ |
| Cutting Item Count (CICT) | 4 | Flute Count (NOF) | 4 |
| Overall Length (OAL) | 8″ | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Type | Round | Style | MEW |
| Application | Facing | Shouldering | Slotting | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Angle | 90 Degrees |
| Master Insert Identification (MIID) | LOMU150504ER-GM | LOMU150508ER-GM | LOMU150510ER-GM | LOMU150512ER-GM | LOMU150516ER-GM | LOMU150520ER-GM | LOMU100408ER-SM | LOMU150508ER-SM | LOMU100408ER-GH | LOMU150508ER-GH | Series/List # | M-FOUR |
| Head Length (LH) | 2.069″ | Measurement Type | Inch |
Product Features
| Family Description | Alternate Manufacture # MEW1500S1258154T | Country of Origin | USA |
Shipping Info
Package Weight
2.0500
