MFSN 88040RS323TG 40.00MM
Indexable End Mill; 40 mm Dia. × 32 mm Shank Dia. × 110 mm OAL × 5 mm LU ; 3 FL ; Round Shank ; Series MFSN88
| Cutting Diameter (DC/DCX) | 40 mm | Usable Length (LU) | 5 mm |
| Cutting Diameter (DC) | 40 mm | Flute Count (NOF) | 3 |
| Cutting Item Count (CICT) | 3 | Coolant Supply Property (CSP) | Coolant Thru |
| Overall Length (OAL) | 110 mm | Style | MFSN |
| Shank Type | Round | Cutting Direction (HAND) | Right Hand |
| Application | Facing | Shouldering | Slotting | Angle | 88 Degrees |
| Connection Diameter Machine Side (DCONMS) | 32 mm | Series/List # | MFSN88 |
| Master Insert Identification (MIID) | SNMU130508EN-GM | SNMU130508EN-SM | SNMU130508EN-GH | Measurement Type | Metric |
| Head Length (LH) | 30 mm | Cutting Diameter Maximum (DCX) | 40 mm |
| Tool Type | End Mill |
Product Features
| Family Description | Alternate Manufacture # MFSN88040RS323TG | Country of Origin | Japan |
Shipping Info
Package Weight
3.4209
