SCD 0187-138-0187ACP5 IC908
Solid carbide drills with coolant holes. Drilling depth 5xD.
| Drill Bit Size / Cutting Diameter (DC) | 0.187″ | Cutting Edge Material | Carbide |
| Decimal Equivalent | 0.2638″ | Tool Type | Solid Carbide Drills |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 6.7 mm | Grade | IC908 |
| Length Group | 5xD | Measurement Type | Inch |
| Coating | TiAlN | Series/List # | 2464 |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi-Temp Alloys | | Usable Length (LU) | 1.13″ |
| Connection Diameter Machine Side (DCONMS) | 0.187″ | Length Chip Flute (LCF) | 1.38″ |
| Coolant Supply Property (CSP) | External | Overall Length (OAL) | 2.91″ |
| Point Angle (SIG) | 118 Degrees | Flute Count (NOF) | 5 |
| Flute Helix Angle (FHA) | 30 Degrees | Cutting Direction (HAND) | Right Hand |
| Shank Type | Round | Body Material | Carbide |
| Shape | Jobber Drill |
Product Features
| Family Description | Solid carbide drills with coolant holes. Drilling depth 5xD. | Country of Origin | KR |
Shipping Info
Package Weight
.0320
