22J3G-20041D3R02
| Application | | Facing | Shouldering | Slotting | | Flute Count (NOF) | 4 |
| Cutting Diameter (DC) | 2″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 4 | Measurement Type | Inch |
| Depth of Cut Maximum (APMX) | 2.8″ | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 1″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 4.17″ | Ramping Angle Maximum (RMPX) | 4 Degrees |
| Connection Thread Size | M10 |
Product Features
| Family Description | Produces smooth blend between stations (visible line but no step on side wall) 32-63 Ra surface finishes when engaging the wiper (WEP) Insert Corner: .015″, .031″, .062″ & .093″ R | Country of Origin | Usa |
Shipping Info
Package Weight
0.003
