PLX D80-32-12
| Application | | Plunging & Recessing | | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter (DC) | 80mm | Flute Count (NOF) | 8Teeth |
| Cutting Item Count (CICT) | 8 | Measurement Type | Metric |
| Depth of Cut Maximum (APMX) | 0.28″ | Tool Type | Plungers Cutters |
| Face Effective Cutting Edge Count (ZEFF) | 2 Teeth | Functional Length (LF) | 1-1/4″ |
| Overall Length (OAL) | 50 mm | Body Material | Steel |
| Connection Thread Size | M10 | Tool Cutting Edge Angle (KAPR) | 2 Degrees |
Product Features
| Family Description | Side shell mill plungers carrying XCMT 120408TR inserts. | Country of Origin | Israel |
| Remarks | With holes for internal coolant |
Shipping Info
Package Weight
2.314
Related Documentation
