BT40SEM22X60C
Shell Mill Holder; 40 Shank Dia. ; 1.299″ Body Length ; CAT50 Shank Size ; CAT Shank
| Connection Diameter Machine Side (DCONMS) | 40 | Material | Steel |
| Shank Size (SS) | CAT50 | Shell Mill Pilot Size | 1-1/2″ |
| Functional Length (LF) | 2.362″ | Flange Diameter (DF) | 3.380″ |
| Body Length (LB) | 1.299″ | Tool Type | BT |
| Shank Type | CAT | Measurement Type | Inch |
| Overhang Length (L2) | 6″ | Protruding Length (LPR) | 6″ |
| Hex Size | 5/8″ |
Product Features
| Family Description | Shell mill holder with coolant hole with BT shank (Extra long type ) | Country of Origin | Italy |
| Remarks | If the "B type" option is required, the plug screw must be removed from the flange cooling hole (use a 2 mm hex key). Wrench is not included. |
Shipping Info
Package Weight
2.5
