DIN6987150EM18X63E
| Connection Size (CSI) | 50 | Measurement Type | Metric |
| Connection Diameter Workpiece Side (DCONWS) | 18 mm | Connection Retention Knob Thread Size (CRKS) | M24 |
| Body Diameter (BD) | 50 mm | Shank Size (SS) | 50 |
| Body Length Maximum (LBX) | 43.9 mm | Tool Type | DIN 69871 |
| Protruding Length (LPR) | 63 mm | Body Length (LB) | 43.9 mm |
| Overall Length (OAL) | 63 mm | Body Material | Steel |
| Application | | Tapered shape interface | |
Product Features
| Family Description | Screw locking endmill holders for whistle notch with DIN69871 shank | Country of Origin | Israel |
| Remarks | Add B for coolant through the flange. |
Shipping Info
Package Weight
0.009
