CAT40 ER16X5.906 B
Collet Chuck ; ER16 Connection Size ; 1.11″ Body Dia. ; 0.022″ Min. Capacity
| Connection Size (CSI) | ER16 | Tool Type | DIN 69871 |
| Body Diameter (BD) | 1.11″ | Coolant Supply Property (CSP) | Through Hole |
| Protruding Length (LPR) | 5.906″ | Connection Diameter Minimum Workpiece Side (DCONNWS) | 0.022″ |
| Body Length Maximum (LBX) | 5.156″ | Measurement Type | Inch |
Product Features
| Family Description | DIN 6499 ER collet chucks with Caterpillar form AD/B tapered shanks | Country of Origin | Turkey |
| Remarks | B is the designation for coolant through flange. |
Shipping Info
Package Weight
3.747
