THDL 31.7-14T20-IQ
Grooving Toolholder; 1-1/4″ × 1-1/4″ Shank Size × 0.787″ Max Depth × 7″ OAL ; Steel
| Cutting Depth Maximum (CDX) | 0.787″ | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Height (H) | 1-1/4″ | Application | | Ext. Grooving | |
| Shank Width (B) | 1-1/4″ | Body Material | Steel |
| Body Width (WB) | 0.512″ | Tool Type | Wide Profiling Tools |
| Functional Width (WF) | 0.99″ | Measurement Type | Inch |
| Head Length (LH) | 1.18″ | Head Bottom Offset Height (HBH) | 0.32″ |
| Overall Length (OAL) | 7″ |
Product Features
| Family Description | External holders for wide grooving inserts | Country of Origin | Israel |
Shipping Info
Package Weight
3.159
