11EL A 55 IC250
| Thread Standard | THFT | | Applicable Material | Steel | Stainless Steel |
| Inscribed Circle Diameter (IC) | 1/4″ | Shape | 60° Triangle |
| Insert Length (INSL) | 0.433″ | Cutting Item Count (CICT) | 2 |
| Thread Pitch (TP) | 3 mm | Thread Pitch Minimum (TPN) | 0.5 mm |
| Corner Radius (RE) | 0.002″ | Thread Pitch Maximum (TPX) | 1.5 mm |
| Grade | IC250 | Tool Type | Threading Regular Insert |
| Coating | TiCN|TiN | Measurement Type | Inch |
| Cutting Edge Material | Carbide | Body Material | Carbide |
| Cutting Position | External | Thread Form Type (THFT) | M60 |
| Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
Product Features
| Family Description | External 55° partial profile, laydown threading inserts. ER/L - ground periphery and rake, ERB - with a chipformer and peripherally ground, ERM - with a chipformer. Application: general industry. | Country of Origin | Israel |
| Remarks | For insert identification system, click on "More Info" For threading between walls use GRIP-type inserts TIP-WT, GEPI-WT, TIPI-WT |
Shipping Info
Package Weight
.0230
