16IR 0.75 ISO IC228
Laydown Threading Insert; 16IR 0.75 ISO IC228 60 Triangle ; 0.75 mm TP × 0.63″ Length × 3/8″ IC ; Carbide ; TiCN+TiN
| Thread Standard | THFT | | Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Inscribed Circle Diameter (IC) | 3/8″ | Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys |
| Insert Length (INSL) | 0.63″ | Shape | 60° Triangle |
| Thread Pitch (TP) | 0.75mm | Cutting Item Count (CICT) | 1 |
| Corner Radius (RE) | 0.002″ | Tool Type | Threading Regular Insert |
| Grade | IC228 | Measurement Type | Inch |
| Coating | TiCN|TiN | Body Material | Carbide |
| Cutting Edge Material | Carbide | Thread Form Type (THFT) | M60 |
| Cutting Position | Internal |
Product Features
| Family Description | Internal, ISO metric (DIN13 12-1986 class 6H) laydown threading inserts. ER/L - ground periphery and rake, ERB - with a chipformer and peripherally ground, ERM - with a chipformer. Application: general industry. | Country of Origin | Israel |
| Remarks | For Insert Identification System, click on "More Info" Tolerance: Class 6H |
Shipping Info
Package Weight
.013
