22IR 5 TR IC228
Laydown Threading Insert; 22IR 5 TR IC228 60 Triangle ; 5 mm TP × 0.866″ Length × 1/2″ IC ; Carbide ; TiCN+TiN
| Thread Standard | THFT | | Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Inscribed Circle Diameter (IC) | 1/2″ | Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys |
| Insert Length (INSL) | 0.866″ | Shape | 60° Triangle |
| Thread Pitch (TP) | 5mm | Cutting Item Count (CICT) | 2 |
| Corner Radius (RE) | 0.21 mm | Tool Type | Threading Regular Insert |
| Grade | IC228 | Measurement Type | Inch |
| Coating | TiCN|TiN | Body Material | Carbide |
| Cutting Edge Material | Carbide | Thread Form Type (THFT) | M60 |
| Cutting Position | Internal |
Product Features
| Family Description | Internal trapeze shaped, DIN 103 laydown threading inserts, for feed screws. | Country of Origin | Israel |
| Remarks | For Insert Identification System, click on "More Info" Tolerance: Class 7H |
Shipping Info
Package Weight
.026
