16IR 12 UN IC228
Laydown Threading Insert ; 3 mm TP ; 12 TPI ; 60 Triangle Shape ; 0.63″ Length ; 3/8″ IC ; THFT | ; Carbide ; IC228 ; TiCN|TiN
| Thread Standard | THFT | | Cutting Position | Internal |
| Inscribed Circle Diameter (IC) | 3/8″ | Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Insert Length (INSL) | 0.63″ | Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys |
| Thread Pitch (TP) | 3 mm | Shape | 60° Triangle |
| Threads per Inch (TPI) | 12 | Cutting Item Count (CICT) | 1 |
| Corner Radius (RE) | 0.005″ | Tool Type | Threading Regular Insert |
| Grade | IC228 | Measurement Type | Inch |
| Coating | TiCN|TiN | Body Material | Carbide |
| Cutting Edge Material | Carbide | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | Internal American UN, full profile (UN, UNC, UNF, UNEF), laydown threading inserts. IR/L - Ground periphery and rake, IRB - with a chipformer and peripherally ground, IRM - With a chipformer. Application: general industry. | Country of Origin | Israel |
| Remarks | For Insert Identification System, click on "More Info" Tolerance: class 2B,ANSI B1, 3M-1986 |
Shipping Info
Package Weight
0.013
