16ER 11.5 NPT IC508
| Thread Standard | THFT | | Cutting Position | External |
| Inscribed Circle Diameter (IC) | 3/8″ | Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Insert Length (INSL) | 0.63″ | Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Non-Ferrous Metals|Hi-Temp Alloys |
| Thread Pitch (TP) | 3 mm | Shape | 60° Triangle |
| Threads per Inch (TPI) | 11.5 | Cutting Item Count (CICT) | 1 |
| Corner Radius (RE) | 0.004″ | Tool Type | Threading Regular Insert |
| Grade | IC508 | Measurement Type | Inch |
| Coating | TiCN|TiN | Body Material | Carbide |
| Cutting Edge Material | Carbide | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | External NPT (National Pipe Threads) full profile laydown threading inserts. ER/L - ground periphery and rake, ERB - with a chipformer and peripherally ground, ERM - with a chipformer. Used for steam, gas and water pipes. | Country of Origin | IL |
| Remarks | For Insert Identification System, click on "More Info". For threading between walls use GRIP-type insert TIP-NPT. National Pipe Threads ANSI/ASME B1.20.1-1983 |
Shipping Info
Package Weight
.0230
