16ER 40 W IC508
| Thread Standard | THFT | | Cutting Position | External |
| Inscribed Circle Diameter (IC) | 3/8″ | Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Insert Length (INSL) | 0.63″ | Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Non-Ferrous Metals|Hi-Temp Alloys |
| Thread Pitch (TP) | 3 mm | Shape | 60° Triangle |
| Threads per Inch (TPI) | 40 | Cutting Item Count (CICT) | 1 |
| Corner Radius (RE) | 0.002″ | Tool Type | Threading Regular Insert |
| Grade | IC508 | Measurement Type | Inch |
| Coating | TiCN|TiN | Body Material | Carbide |
| Cutting Edge Material | Carbide | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | External Whitworth (BSW, BSF, BSP), full profile laydown threading inserts. ER/L - Ground periphery and rake, ERB - With a chipformer and peripherally ground, ERM - With a chipformer. Application: fittings and pipe couplings. | Country of Origin | Israel |
| Remarks | For Insert Identification System, click on "More Info" For threading between walls use GRIP-type insert TIP-BSW. Tolerance: Medium Class |
Shipping Info
Package Weight
.0160
