Corner Radius End Mill; 1/8″ Dia. × 1/2″ LOC × 1/8″ Shank Dia. × 1-1/2″ OAL ; 5 FL ; Carbide ; Uncoated ; Series 5500
Corner Radius End Mill; 1/8″ Dia. × 1/2″ LOC × 1/8″ Shank Dia. × 1-1/2″ OAL ; 5 FL ; Carbide ; Uncoated ; Series 5500
| Cutting Diameter (DC) | 1/8″ | End Shape | Corner Radius |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | Usable Length (LU) | 1/2″ |
| Depth of Cut Maximum (APMX) | 1/2″ | Corner Radius (RE) | 0.01″ |
| Overall Length (OAL) | 1-1/2″ | Coolant Supply Property (CSP) | External |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.125″ |
| Coating | Uncoated | Measurement Type | Inch |
| Flute Count (NOF) | 5 | Series/List # | 5500 |
| Flute Helix Angle (FHA) | 35 Degrees |
Product Features
| Remarks | •Fullerton's 5500 Series MATRX EM-1 End Mills multi-flute design allows for ultimate material removal rates•The MATRX EM-1 allows for high shear and low cutting forces that provide a clean edge without fibers•Chipbreakers produce a clean shearing of fibers•Right hand flute•Right hand spiral•Solid carbide•Cutter diameter tolerance: +.0000″"-.0005 / +0.000-0.013mm•Shank diameter tolerance: h6•Available uncoated and with FC-1 CVD diamond coating | Country of Origin | USA |
Shipping Info
Package Weight
.015
