HM90 E90AD-D1.5-2-W1.25-C
| Cutting Diameter (DC/DCX) | 1-1/2″ | Head Length (LH) | 1-1/2″ |
| Cutting Diameter (DC) | 1-1/2″ | Functional Length (LF) | 3.359″ |
| Cutting Item Count (CICT) | 2 | Tool Type | 90° indexable endmills |
| Depth of Cut Maximum (APMX) | 0.56″ | Flute Count (NOF) | 2 |
| Overall Length (OAL) | 4-1/2″ | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Type | Weldon | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Ramping Angle Maximum (RMPX) | 4 Degrees | Cutting Direction (HAND) | Right Hand |
| Application | | Counter Boring | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Body Material | Steel |
| Master Insert Identification (MIID) | ADKT 1505PDTR | Connection Code Machine Side (CCMS) | Cylindrical |
| Weight of Item (WT) | 1.74 Lbs |
Product Features
| Family Description | 90° endmills carrying HM90 ADKT-1505... inserts. | Country of Origin | Israel |
| Remarks | For adaptation, click on "More Info" Thinner insert ADM. 1503.. mounted on TSP-15R seat |
Shipping Info
Package Weight
1.742
