Corner Radius End Mill; 12 mm Dia. × 5 mm LOC × 12 mm Shank Dia. × 110 mm OAL ; 4 FL ; Carbide ; Blue Coating ; Series G854
SQ End Mill; 12 mm Dia. × 5 mm LOC × 12 mm Shank Dia. × 110 mm OAL ; 2 mm RE ; 4 FL ; 25 mm LBS ; Carbide ; AlTiSiN ; Series G854
| Cutting Diameter (DC) | 12 mm | Usable Length (LU) | 25 mm |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Applicable Material | | Steel | Hard Materials | |
| Depth of Cut Maximum (APMX) | 5 mm | Corner Radius (RE) | 2 mm |
| Overall Length (OAL) | 110 mm | Neck Diameter (DN) | 11 mm |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.4724″ |
| Coating | AlTiSiN | Measurement Type | Metric |
| Flute Count (NOF) | 4 | Series/List # | G854 |
| Flute Helix Angle (FHA) | 0 Degrees | Cutting Direction (HAND) | Right Hand |
| Shank Type | Round | Center Cutting | Yes |
| End Shape | Corner Radius |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Length
4.75
Package Width
0.75
Package Height
0.75
Package Weight
0.4
