14″ × 40″ Gear Head Toolroom Lathe; Model 1440A , (12) 40-1800 RPM Spindle Speeds; D1-6 Spindle; Spindle Hole Dia.1 1/2; 4hp 220/440V, 3 ph
| Swing Distance | 14″ | Cross Slide Travel | 6-1/2″ |
| Distance Between Centers | 40″ | Swing Over Gap | 20″ |
| Horsepower | 4 hp | Tailstock Taper | 3MT |
| Voltage | 220 V/440 V | Maximum Thread Per Inch | 4″ |
| Phase | 3 Phase | Minimum Threads Per Inch | 112 |
| Spindle Taper | D1-4 | Model No | 1440A |
| Spindle Hole Diameter | 1-1/2″ | Spindle Type | D1-4 |
| Number of Spindle Speeds | 12 | Swing Over Crossslide | 8-1/4″ |
| Weight | 2,491 lbs | Inch Thread Range | 4-112 TPI (40 changes) |
| Maximum Spindle Speed | 1,800 RPM | Metric Thread Range | 0.45-7.50 mm (24 changes) |
| Minimum Spindle Speed | 40 RPM |
Product Features
| Remarks | •Inch/metric threading •Removable gap •T-slotted compound •All cast iron construction •Hardened and precision ground bed ways •Foot brake •Dual dials - inch/metric •F.O.B. FactoryStandard Equipment: •8″ 3-Jaw chuck (D1-4) •8″ 4-Jaw chuck (D1-4) •Steady rest •Follow rest •Full length splash guard •Halogen work light •Taper attachment •Coolant system •Thread dial •Micrometer carriage stop | Country of Origin | Taiwan |
Shipping Info
Hazard Code
T
Shipping Notes
Ships by Truck. Additional Costs Apply.
Package Weight
2491
