| Swing Distance | 16″ | Cross Slide Travel | 11-3/8″ |
| Distance Between Centers | 80″ | Swing Over Gap | 25-1/8″ |
| Horsepower | 10 hp | Tailstock Taper | 5MT |
| Voltage | 220 V | Maximum Thread Per Inch | 1/4″ |
| Phase | 3 Phase | Minimum Threads Per Inch | 60 |
| Spindle Taper | D1-8 | Model No | 16380 |
| Spindle Hole Diameter | 3″ | Spindle Type | D1-8 |
| Number of Spindle Speeds | 21 | Swing Over Crossslide | 9-3/8″ |
| Weight | 6,380 lbs | Inch Thread Range | 1/4-60 TPI (64 changes) |
| Maximum Spindle Speed | 2,000 RPM | Metric Thread Range | 0.50-120 mm (64 changes) |
| Minimum Spindle Speed | 20 RPM |
Product Features
| Remarks | •Standard Features: Hardened and ground bedways Big 3 thru hole Removable gap Inch/metric threads Feed reversing at the apron Hardened and ground cross slide ways 4-way rapid traverse Single lever control for feeds and rapids Full length splash guard Sliding chuck guard with limit switch •Standard Accessories Include: Thread dial Steady rest with roller tips Follow rest Coolant system 3-Jaw chuck (10 ) Carriage stop Work light Taper Attachment •1 Year Warranty on Parts & Labor •6 Months on all Electrical •F.O.B. Oklahoma City, OK | Country of Origin | Bulgaria |
Shipping Info
Hazard Code
T
Shipping Notes
Ships by Truck. Additional Costs Apply.
Package Length
154.00000
Package Width
48.00000
Package Height
60.00000
Package Weight
6380
