CM D.75-B-W1.00
| Cutting Diameter (DC/DCX) | 3/4″ | Head Length (LH) | 3-1/2″ |
| Cutting Diameter (DC) | 3/4″ | Tool Type | Ball nose endmills |
| Cutting Item Count (CICT) | 2 | Corner Radius (RE) | 3/8″ |
| Depth of Cut Maximum (APMX) | 0.51″ | Body Half Taper Angle (BHTA) | 3 Degrees |
| Overall Length (OAL) | 8″ | Front Type | B |
| Shank Type | Weldon | Cutting Direction (HAND) | Right Hand |
| Ramping Angle Maximum (RMPX) | 90 Degrees | Measurement Type | Inch |
| Application | | Profiling | | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 1″ | Cutting Diameter Maximum (DCX) | 3/4″ |
| Weight of Item (WT) | 1.42 Lbs |
Product Features
| Family Description | Ball nose endmills (HELIBALL). | Country of Origin | Israel |
| Remarks | For adaptation, click on More Info. |
