MFH-RAPTOR MICR 0.3750 EM
Indexable End Mill; 3/8″ Dia. × 3/8″ Shank Dia. × 3″ OAL ; 1 FL ; Round Shank ; Series MFH-RAPTOR Micro
| Cutting Diameter (DC/DCX) | 3/8″ | Head Length (LH) | 3/4″ |
| Cutting Diameter (DC) | 3/8″ | Tool Type | High Feed End Mill |
| Cutting Item Count (CICT) | 1 | Flute Count (NOF) | 1 |
| Overall Length (OAL) | 3″ | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Type | Round | Style | MFH |
| Ramping Angle Maximum (RMPX) | 3 Degrees | Cutting Direction (HAND) | Right Hand |
| Application | Facing | Shouldering | Slotting | Ramping | Helical Milling | Plunging | Angle | 10 Degrees |
| Connection Diameter Machine Side (DCONMS) | 3/8″ | Series/List # | MFH-RAPTOR Micro |
| Master Insert Identification (MIID) | LPGT010210ER-GM | Measurement Type | Inch |
Product Features
| Family Description | Alternate Manufacture # MFH0375S375011T3 | Country of Origin | USA |
Shipping Info
Package Weight
0.35
