MFWN 90050RS323T 50.00MM
Indexable End Mill; 50 mm Dia. × 32 mm Shank Dia. × 110 mm OAL × 8 mm LU ; 3 FL ; Round Shank ; Series M-SIX
| Cutting Diameter (DC/DCX) | 50 mm | Tool Type | End Mill |
| Cutting Diameter (DC) | 50 mm | Usable Length (LU) | 8 mm |
| Cutting Item Count (CICT) | 3 | Flute Count (NOF) | 3 |
| Overall Length (OAL) | 110 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Type | Round | Style | MFWN |
| Application | Facing | Shouldering | Slotting | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 32 mm | Angle | 90 Degrees |
| Master Insert Identification (MIID) | PNEU1205ANER-GL | PNMU1205ANER-GM | PNMU1205ANER-SM | PNMU1205ANER-GH | PNEU1205ANER-W | Series/List # | M-SIX |
| Head Length (LH) | 30 mm | Measurement Type | Metric |
Product Features
| Family Description | Alternate Manufacture # MFWN90050RS323T | Country of Origin | S.Korea |
Shipping Info
Package Weight
2.0545
