3/16″ Dia. × 3/16″ Shank × 3/8″ DOC × 100 mm OAL, Carbide, Cr, 4 Flute, Square, Solid End Mill
SQ End Mill; 3/16″ Dia. × 3/8″ LOC × 3/16″ Shank Dia. × 100 mm OAL ; 0.3 mm RE ; 4 FL ; 40 mm LBS ; Carbide ; CrN ; Series 3620
| Cutting Diameter (DC) | 3/16″ | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 3/16″ | Usable Length (LU) | 40 mm |
| Depth of Cut Maximum (APMX) | 3/8″ | Corner Radius (RE) | 0.3 mm |
| Overall Length (OAL) | 100 mm | Tool Type | High Performance |
| Cutting Edge Material | Carbide | Style | Square |
| Coating | CrN | Decimal Equivalent | 0.1875″ |
| Flute Count (NOF) | 4 | Measurement Type | Inch |
| Shank Type | Round | Series/List # | 3620 |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Length
2.10000
Package Width
.55000
Package Weight
0.035
